Zed Purlins
Our product range consists of a fully compatible range of roof and side rail zed purlins, made from cold rolled steel in depths ranging from 121mm to 265mm deep. In addition, our sections come with a wide range of compatible accessories and can be supplied for the majority of cladding types and designs.
All our zed purlins are manufactured from pre-hot dipped galvanised steel, G275 coating and with minimum yield strength of 450N/mm².
Ideal For:
- Agricultural Buildings
- Industrial Buildings
- Commercial Buildings
- Refurbishments
Cee Sections
Steel Sections Cee sections are a comprehensive range of channels for a diversity of applications. Primarily for use within mezzanine floors, Cee sections can also be applied in many other circumstances such as door framing, roof trimming, window trimming, brickwork restraints, parapet rails and side rails.
Our product range is made from cold rolled steel in depths ranging from 140mm to 265mm deep. In addition, our sections come with a wide range of compatible accessories and can be supplied for the majority of applications and designs.
All our Cee sections are manufactured from pre-hot dipped galvanised steel, G275 coating and with minimum yield strength of 450N/mm².
Ideal For:
- Agricultural Buildings
- Industrial Buildings
- Commercial Buildings
- Refurbishments
- Ceiling Supports
- Mezzanine Floors
Eaves Beams
Steel Sections Eaves Beam is a purpose-designed profile for use as an eaves purlin, top sheeting rail and gutter support. We offer 2 profiles for our eaves beams, as recessed profile available in 190mm x 2.0mm thick and a flat faced range with the following depths available 190mm x 2.0mm, 235mm x 2.0mm, 265mm x 2.0mm and 265mm x 2.5mm thick all available with an angled top flange from 0° – 25°.
Ancilliary Items
For a full range of Zed Purlin, Cee Section and Eaves Beam accessories please download our detailing sheets or contact a member of staff on 0121 556 9111 for further info.
- Anti-Sag Bars
- Side Rail Supports
- Diagonal Tie Wires
- Eaves Beam Side Rail Supports / Ties
- Apex Ties
- Bolt on & Weld on Cleats
- Inset Cleats
- Trimmer Cleats
- Rafter Stays
- Cleader Rails
